Thread the exposed inner wires of the opposite end of the cable into the OBD-II CAN connector. Connectors: GM 12Pins OBD1 male connector OBD2 16pins female connector. If you want the ultimate in compatibility for all years of OBD1 cars, including your 94 and 95, buy the bare pin cable. Product Description: Compatible with GM cars made before 1996. This 16 pin shell cable will not plug into the 12 pin style OBD1 ALDL connector found on most 84 to 95 cars. If you have a 1996 or later obd-2 car, buy our OBD2 Allinone scan tool.
The 94 and 95 cars that are equipped with the OBD2 style connector actually have OBD1 ECM/PCM systems behind them. This cable will not work on 1996 and later OBD2 cars! Although the connector style is the same, 96 and later cars use the OBD2 communications protocol, and are not backward compatible to earlier year cars. Package Included: 1 x GM 12-Pin to OBDII 16-Pin Cable. Specifications: Type: Cables, adapters & sockets Connector: GM 12 pins male connector OBDII 16pins female connector Car Maker: Replacement for GM Item Length: 41.5cm / 16.3 Package Weight: 102g.
#Diy gm obd1 cable to 16 pin connector usb serial
The 8192 baud serial data comes off of pin 9 in these connectors. This +12v power arrangement allows us to build a simpler cable with no lighter plug +12v needed. And please note that this item is just a cable, not a scanner or diagnostic tool. Please check under your 94-95 car's dash and make sure it has the 16 pin style connector before ordering this cable.ĩ4 and 95 cars that are equipped with the 16 pin OBD2 style connector have built in +12v power coming off of pin 16 and ground coming off of pin 5. See our GM OBD1 home page for references and diagrams of the connector styles, or see the OBD2 diagram below. This cable is the most convenient to use if your car is equipped with the 16 pin connector style, as it allows you to just feel under the dash to plug it in. This cable is for 19 OBD1 cars equipped with the 16 pin OBD2 style connector (Camaros, Firebirds, Corvettes, and LT1 equipped cars are a few), and has a 16 pin OBD2 connector shell to plug in under your car's dash to interface to your car's ECM/PCM. OBD2 All-In-One Scan Tool w/ USBĪLDL (GM OBD1) Cable with 16 pin ConnectorĪLDL (GM OBD1) Cable with 16 pin Connector, Serial OBD Diagnostics, Inc.OBD Diagnostics, Inc. If you have the GM 16 pin OBDII style connector used on some 94-95 OBDI cars, buy the 16 pin cable. If you have some other connector configuration other than the GM 12 pin (such as Lotus cars) or a mid-1980's GM car with the serial data on pin D, buy the bare pin cable. Pin M indicates 8192 baud and pin E indicates 160 baud rate serial communication speed. This cable works on cars that have the serial data pin on pin M or pin E of the GM 12 pin OBD1 ALDL connector, which is most every 1982 to 1995 GM car. See our GM OBD1 home page for references and diagrams of the connectors styles. This cable is the most convenient to use if your car is equipped with the 12 pin connector style, as it allows you to just feel under the dash to plug it in. This cable has a 12 pin OBD1 connector shell to plug in under your cars dash to interface to your cars ECM. OBD2 All-In-One Scan Tool w/ USBĪLDL (GM OBD1) Cable with 12 pin ConnectorĪLDL (GM OBD1) Cable with 12 pin Connector, USB
